3-phase spot HORUS, 220-240V AC/50-60Hz, 20W, 4000K, black

3-Phase Spotlight HORUS, 230V AC, UGR <19, switchable, 20W

The 3-Phase Spotlight HORUS is a powerful lighting element with a power consumption of 20W. Operating at a voltage of 230V AC and with a UGR value less than 19, it provides glare-free lighting. The spotlight is switchable and is ideal for use on ceilings and walls indoors.

Size and Design

The HORUS spotlight has an elegant design with a size of Ø/ L: 8/ 18.5 cm and a protrusion-H of 5 cm. The slim housing in matte black and the frosted housing surface give it a modern appearance. The shape of the light is round and the beam angle is 40°, allowing for optimal light distribution.

Light Quality and Energy Efficiency

The spotlight uses 14x SMD LED 2835 light sources with a luminous intensity of 3173cd and a luminous flux of 1785lm. The light color is neutral white with a color temperature of 4000K and a color rendering index of 80Ra. The energy efficiency class of the spotlight is F and it has a luminous efficacy of 89.25lm/W.

Installation and Functions

The HORUS spotlight is easy to install and can be rotated and tilted to ensure the optimal alignment of light. It has a defined beam angle that guarantees low glare. The spotlight is not dimmable, but switchable and has a lifespan of 54000 hours. It is available in different housing and light colors as well as power levels.

Additional Information and Technical Details

The HORUS spotlight has an IP protection rating of IP20 and can be operated in a temperature range of -20 to +40°C. It has a power factor of 0.9 and a switching cycle of 30000. The starting time is 0.5s and the color consistency (MacAdam) is 6 SDCM. The product comes with a 3-phase adapter and has a mains connection for easy installation.
