LED funiture built-in downlight N 5020 COB (3 pc. + accessories), 3x 3.3W 3000K, fixed optics, brushed nickel

nobilé



Are you a retailer or business customer (commercial/freelancer)? Secure special B2B prices now.

Modern Set of 3 LED Furniture Recessed Lights

The LED furniture recessed light N 5020 COB 3-piece set offers an efficient and stylish lighting solution for your furniture. With three individual lights, each equipped with a 3.3 watt COB LED, the set produces a pleasant warm white light at 3000 Kelvin. The lights are specially designed for furniture applications and impress with their compact size of 6.6 cm diameter and only 1.8 cm installation depth, allowing them to seamlessly integrate into various pieces of furniture.

High-Quality Technical Features

Each recessed light provides a luminous flux of 570 lumens and a color rendering index of 95 Ra, meaning colors appear especially natural and vibrant under this lighting. The light sources are included in the delivery and have an impressive lifespan of up to 50,000 hours. The set operates with a constant current supply of 350 mA and a voltage of 220 to 240 volts, ensuring consistent and reliable light quality.

Practical and Safe Accessories Included

The complete set includes not only the three LED lights but also all necessary accessories for easy installation. These include an AMP distributor, connection cables with a length of 30 cm, end contact short-circuit bridges, as well as a driver and extension cable. The power connection is made via a 2-pole AMP plug system with Euro plug, which facilitates installation and guarantees a secure connection. Protection class 2 additionally ensures safe operation.

Design and Materials for High Quality

The recessed lights are made from high-quality materials, including glass, plastic, and steel with an elegant brushed nickel finish. This design not only provides a modern look but also ensures durable and robust workmanship. The beam angle of 86° provides broad and even illumination of your furniture areas, contributing to a pleasant atmosphere.

Easy Installation and Flexible Use

The set is designed so that the installation spacing can be freely chosen, allowing you to optimally adapt the lights to your needs. During installation, care should be taken not to cover the lights with insulating material and to ensure sufficient convection to avoid overheating. The color consistency is at 3 SDCM, guaranteeing uniform light color across all three lights. With a total weight of only 203 grams, the set is also very lightweight and unobtrusive.

Colour:
brushed nickel
Glass color:
satined
Reflector color:
silver
Dimension:
luminaire-Ø∕ H: 6,6∕ 1,8 cm
Material:
glass
plastic
steel
Weight:
0,203 kg
Product type:
furniture recessed luminaire
Bulbs in delivery:
yes
Accessories:
AMP distributor - included in delivery
connection cable - included in delivery
end contact short-circuit bridge - included in delivery
driver - included in delivery
extension cable - included in delivery
Application area:
only suitable for indoor use
Field of application:
furniture
Operating voltage:
220 - 240 V
Dimmable:
no
Constant current:
350 mA
Power consumption:
9,9 W
Emitting angle:
86 °
Bulb type:
LED
Lamps/bulbs:
3x COB LED, 3.3W
Number of bulbs:
3
Light colour:
warm white
Beam direction:
symmetriccal
Light flux:
570 lm
Colour temperature:
3000 K
Average life span of a bulb in hours:
50000 h
Colour rendering index:
95 Ra
Fitting depth:
1,8 cm
Fitting opening Ø:
5,8 cm
Length of connection lead:
30 cm
Protection class:
2
IP-protection class:
IP20
Additional information:
System power: 15W
ambient temperature:
0 - 25 °C
Article number:
NO-1550200900
Purchasing quantity:
1 piece
Brand:
nobilé
Manufacturer:
nobilé
Manufacturer information
nobilé AG, Wächtersbacher Str. 78, 60386, Frankfurt/Main, Germany, nobile@nobile.de
