LED Furniture luminaire ECOLITE F HO, 21W, 3000K, IP20, white

Efficient and Flexible Lighting System

The LED surface-mounted linear luminaire EcoLite F HO by Hera offers an efficient and flexible lighting solution for indoor spaces. With an energy consumption of 22kWh/1,000 h and a power consumption of 21.5W, it produces a warm white light color with a luminous flux of 2300lm. Thanks to the through-wiring, multiple luminaires can be installed in a row to create homogeneous light bands.

Versatile Applications

The LED linear luminaire is ideal for use as an under-cabinet light, furniture light, or object light in dry indoor spaces. With a beam angle of 170° and a diffuse light diffuser, it creates a pleasant light distribution. The white housing made of plastic and metal ensures a high-quality appearance.

Simple Installation and Expansion

Thanks to the surface mounting clips and the rigid direct connector, the installation of the LED linear luminaire is straightforward. The individual luminaires can be connected to light bands with a total power of up to 200 watts. Connection cables and magnet clips are available for comprehensive mounting options.

Technical Details and Accessories

The LED surface-mounted linear luminaire has an integrated LED driver and can be directly connected to a 230V AC mains voltage. The operating device is current-controlled and offers a power factor of 0.89. Additional accessories such as connection cables, mounting magnets, connection cables, and mounting clips are available separately.

Practical Installation Tips

Please note that the appropriate connection cable is required for connecting the first luminaire in the light band. The maximum depth of the frame when installed in a glare shield frame is 10cm, and the minimum width is 5cm. The LED linear luminaire is non-dimmable, and the LED cannot be replaced.
